DaTo ECS-011E EV Charging Station 11kW
Upgrade your EV charging with the DaTo ECS-011E 11kW smart EV charging station. Featuring Type 2 connector, IP65 protection, fast charging, and app-based control—ideal for home, commercial & semi-public use.
DaTo ECS-011E EV Charging Station 11kW | Type 2 Wall-Mounted Smart EV Charger | 400V AC Fast Charger
Smart EV Charging Anywhere
The DaTo ECS-011E EV Charger is engineered to deliver fast and efficient charging for modern electric vehicles. Designed for flexibility, it fits seamlessly into home garages, business facilities, and semi-public charging environments.
With smart app integration, users can monitor and control charging sessions, making EV charging more convenient and data-driven.
Technical Specifications
| Specification | Details |
|---|---|
| Model | ECS-011E |
| Rated Voltage | 400V AC |
| Power Supply | 3P + N + PE |
| Rated Current | 15A |
| Rated Power | 11kW |
| Frequency | 50/60Hz |
| Charging Connector | Type 2 |
| Installation | Wall-mounted |
| Enclosure Material | Plastic PC |
| Protection Level | IP65 |
| Impact Protection | IK08 |
| RCD Protection | Type A + 6mA DC |
| Operating Temperature | -30°C to +50°C |
| Humidity Range | 5% – 95% |
| Charging Time | Approx. 6–8 hours |
| Connectivity | WiFi / Ethernet |
| Protocols | OCPP 1.6 JSON |
Ideal Applications
- Residential homes
- Commercial parking spaces
- Offices & business centers
- Semi-public charging stations
Smart Connectivity
Control your EV charger using a dedicated mobile app:
- Start/Stop charging remotely
- Monitor energy consumption
- Access charging history
- Download usage reports
Safety & Protection
- Overcurrent Protection
- Residual Current Protection (RCD)
- IP65 Dust & Water Resistance
- IK08 Impact Resistance
- Temperature Monitoring
